Acetal POM C & H
Acetal, chemically known as polyoxymethylene is a semi-crystalline engineering thermoplastic. Acetal POM materials are strong, rigid and have a low coefficient of friction. Due to their exceptional creep resistance and low moisture absorption, TECAFORM Acetal is an excellent material for parts that require a high degree of dimensional stability. Available in a range of copolymers (POM-C) and homopolymers (POM-H).
Excellent machinability
High strength, rigidity and toughness
Outstanding wear resistance and sliding properties
Availability
Rod
3mm to 600mm OD
Tube
10mm ID to 435mm OD
Sheet
1mm to 300mm Thick
Colours
Natural, Black, Blue, Light Blue, Ivory, Grey, Yellow, Orange, Red, Green, Brown
Modified Grades
Yes
Cut To Size
Yes, however some grades have minimum order quantity
Features
POM-C & POM-H
TECAFORM Acetal POM is available as a copolymer (POM-C) or homopolymer (POM-H). Acetal POM-C is more resistant to hydrolysis, hot water and hot air. It has higher chemical resistance and lower melting temperature. Acetal POM-H offers higher mechanical properties such as strength, creep and hardness and generally exhibits better wear resistance.
Widest Range
High quality Ensinger TECAFORM Acetal products are available in a range of standard and advanced grades, stock shapes and colours. Natural unfilled, solid lubricant, anti-static, conductive carbon, metal detectable and medical grades available. FDA and EU10/2011 food grade compliant materials are available for applications that demand it.
Applications
Sliding components like bearings, bushes, gears, rollers, thrust washers and guide rails. Parts that require snap fastenings or assemblies. Electrical insulating parts and parts that require a very high degree of dimensional stability. Parts that require long-life or have thin-walls. Parts requiring FDA or EU10/2011 food compliance.
Long Term Service Temp
'-50ºC to +100ºC
Moisture Absorption
UV Stable
Compressive Strength
Impact Strength
Tensile Strength
Coefficient of Friction
Abrasion Resistance
Cost
TECAFORM Acetal POM Range
| Product Type | Industry Usage | Available Products & Notes *Some items are manufactured & imported on request |
|---|---|---|
| TECAFORM Acetal AH Natural (POM-C) | Food, Mechanical, Oil and Gas, Aircraft and Aerospace, Automotive, Electronic, Medical technologies | Natural Rod, Tube & Sheet White FDA, EU10/2011 & Aerospace approvals |
| TECAFORM Acetal AH Black (POM-C) | Food, Mechanical, Oil and Gas, Aircraft and Aerospace, Automotive technologies | Rod, Tube & Sheet Black *Improved UV Protection FDA, EU10/2011 & Aerospace approvals |
| TECAFORM Acetal AH Blue (POM-C) | Food, Mechanical, Medical, Electronic, Automotive technologies | Rod & Sheet Blue *Optical Detection FDA & EU10/2011 approvals |
| TECAFORM Acetal AH UD Blue (POM-C) | Food, Mechanical, Conveyor, Pharmaceutical technologies | Rod & Sheet Blue *Ultra Detectable Food Grade Acetal for Optical scanners, X-Ray or Metal Detection equipment FDA & EU10/2011 approvals |
| TECAFORM Acetal AH ID Blue (POM-C) | Food & Mechanical technologies | Rod & Sheet Blue *Metal Detectable FDA & EU10/2011 approvals |
| TECAFORM Acetal AH ID Grey (POM-C) | Food & Mechanical technologies | Rod & Sheet Grey *Metal Detectable FDA & EU10/2011 approvals |
| TECAFORM Acetal AH ELS Black (POM-C) | Chemical, Mechanical, Electronic, Automotive technologies | Rod & Sheet Black *Conductive Carbon Black |
| TECAFORM Acetal AH SD Natural (POM-C) | Semi-Conductor, Chemical, Electronic, Food, Mechanical technologies | Sheet Ivory *Anti-Static Agent |
| TECAFORM Acetal AH GF25 Natural (POM-C) | Mechanical, Electronic, Automotive technologies | Rod & Sheet White *25% Glass Fibre Reinforcement |
| TECAFORM Acetal AH TF10 Blue (POM-C) | Food, Mechanical, Medical, Electronic, Automotive technologies | Manufactured on request Blue *10% PTFE Additive |
| TECAFORM Acetal AH LA Blue (POM-C) | Mechanical, Electronic, Automotive technologies | Rod & Sheet Blue Grey *Solid Lubricant Additive |
| TECAFORM Acetal AH LM White (POM-C) | Food, Conveyor, Mechanical, Precision, Automotive, Electronic, Electrical, Medical, Home Appliance technologies | Rod & Sheet White *Laser Markable Additive FDA & EU10/2011 approvals |
| TECAFORM Acetal AH MT Range (POM-C) | Medical, Pharmaceutical, Food technologies | Rod & Sheet Black, Blue, Brown, Green, Grey, Red, Yellow *Medical Applications FDA & EU10/2011 approvals |
| TECAFORM Acetal AD Natural (POM-H) | Food, Mechanical, Aircraft and Aerospace, Automotive, Electronic technologies | Rod, Tube & Sheet White *POM-H manufactured by Ensinger using white DuPont™ Delrin® resin FDA, EU10/2011 & Aerospace approvals |
| TECAFORM Acetal AD Black (POM-H) | Mechanical, Oil and Gas, Aircraft and Aerospace, Electronic, Automotive technologies | Rod & Sheet Black *POM-H manufactured by Ensinger using black DuPont™ Delrin® resin FDA & Aerospace approvals |
| TECAFORM Acetal AD AF Natural (POM-H) | Food, Mechanical, Aircraft and Aerospace, Electronic, Automotive technologies | Rod & Sheet Dark Brown *POM-H with special PTFE fibres |
Have You Read…
Our recent blog post about our extensive range of Acetal POM engineering plastic materials that will meet and exceed your application requirements?
Engineers benefit from machining our high-quality, premium grade Acetal POM materials manufactured by our leading international manufacturer Ensinger GmbH.
View some components manufactured recently from food compliant blue Acetal.
If you are looking for Acetal plastic right now call 0800 102 112. We offer cut to size Acetal plastic in rod, tube and sheet, plus full machining services.
