Chanex® Oregon Bends
Chanex® Oregon Bends are formed into a radius & fastened in place. Available in a range of widths to suit smaller chains such as C2060 to larger chains such as 81X, WH78 & H78. True-Track options are available to centrally guide the chain for scanning applications and improve the life cycle. The perfect, simple solution for replacement idler sprockets.
Reduce idler sprocket replacement costs
Extend chain life due to less chain wear
Quieter site operation due to reduced noise
Availability
Widths
2″, 3″, 3.5″, 4″ & 4.5″
Inside Radius
8″ 10″, 12″, 14″ & 16″
Made To Order
Custom Sizes Available
True-Track Options
Yes
To Suit Chains
C2060, C2060H, LXS-882, C188, 81X, WH78, H78 etc
Material
UHMW-PE thermoplastic
Features
Idler Sprocket Replacement
Chanex® Oregon Bends are the perfect choice as a replacement for idler sprockets offering easier installation, reducing operational costs & power consumption; manufactured from UHMW-PE also reduces noise levels.
Extend Chain Life
Chanex® Oregon Bends are manufactured from UHMW-PE which has a low coefficient of friction enabling very smooth chain flow, protecting the chain from metal to metal contact & proven to extend chain service life.
True-Track
Chanex® Oregon Bends are also available with True-Track options where the chain profile is formed into the Oregon Bend perfectly matching the chain. This allows for optimum chain tracking & also supports the chain roller or barrel & side plates at the same time.
Chanex® Oregon Bends Range
A range of Chanex® Oregon Bends are available. We stock the most common sizes with regular international shipments bringing non-standard sizes for our customers.
Custom sizes can be made by us locally in NZ.
Custom sizes can be made by us locally in NZ.
| Description | Inside Radius Available (inches) | True-Track |
|---|---|---|
| 2" Chanex Oregon Bend | 8" 10" 12" 14" 16" | - - - - - |
| 3" Chanex Oregon Bend | 8" 8" 10" 10" 12" 12" 16" 16" | - Yes - Yes - Yes - Yes |
| 3.5" Chanex Oregon Bend | 8" 10" 12" 14" 16" | - - - - - |
| 4" Chanex Oregon Bend | 8" 10" 12" 14" 16" | Yes Yes Yes Yes Yes |
| 4.5" Chanex Oregon Bend | 8" 10" 12" 14" 16" | - - - - - |
