HDPE PE300
HDPE or high-density polyethylene, exhibits a well-rounded portfolio of properties that sees it widely used in industry. Typically sheet product is extruded with either a gloss or embossed finish.
Easily machined
Excellent chemical resistance
Ease of fabrication and welding
Availability
Rod
Ø20mm to Ø400mm
Tube
Ø15mm ID to Ø200mm OD
Sheet
1mm to 50mm Thick
Colours
Natural, Black, Blue, Red, Yellow, Green, Beige, White
Modified Grades
Yes
Cut To Size
Yes
Features
Versatile
High-density polyethylene (HDPE) is one of the most widely used plastics. With a density range of 0.93–0.97 g/cm³, HDPE has a high strength-to-weight ratio. It has good chemical resistance, weldability and will not delaminate.
Options
HDPE can be extruded in a wide range of colours. It can also be modified for applications such as anti-skid sheet, shielding for x-ray protection, orthopaedic technology and as pipe grade for the water and wastewater industry.
Applications
HDPE is used for cutting boards and playground equipment in various colours with embossed surface finishes. It is also used as partition boards in commercial bathrooms, and for multi-coloured sign boards. HDPE is often used to replace plywood in damp environments, as it will not rot, swell, or chip.
Long Term Service Temp
-73°C to + 82°C
Moisture Absorption
UV Stable
Compressive Strength
Impact Strength
Tensile Strength
Coefficient of Friction
Abrasion Resistance
Cost
HDPE PE300 Range
| Product Type | Description | Available Products & Notes *SOME ITEMS ARE MANUFACTURED & IMPORTED ON REQUEST |
|---|---|---|
| Rods | Ø20mm to Ø400mm | Natural, black |
| Tubes | Ø15mm ID to Ø200mm OD | Black |
| Standard HDPE Sheet | Smooth or grained surface finish | Natural, black, green |
| Densetec™ Cutting Board | Orange peel surface finish, USDA & FDA approved | Natural, red, yellow, light blue, green, beige, black |
| Densetec™ Playground Board | Orange peel surface finish, UV stabilised | White, red, yellow, blue, green, beige, black |
| Densetec™ Sign Board | Orange peel surface finish, UV stabilised | Various twin colour options |
| Densetec™ Marine Board | Desert sand surface finish, UV stabilised | Polar white, seafoam, sand shade, dolphin grey, black |
| Densetec™ Partition Board | Coblestone surface finish | Multiple designer options |
| Densetec™ Shield | Standard 5% boron by weight | Green |
| Densetec™ Anti Skid | Dot or diamond surface finish | Tan, red, yellow, blue, green, black, polar white, seafoam, sand shade, dolphin grey |
| Densetec™ Anti Microbial | Incorporates an antibacterial agent to suppress the growth of bacteria on surfaces | Various surface finish and colour options |
Want to learn more?
Check out our blog post on HDPE sheet uses.
Suppliers
Related Products / Services
UHMWPE Virgin
UHMWPE Virgin - the world’s toughest polymer. Chemically resistant, low coefficient of friction, high abrasion and impact resistance makes this a highly effective material in a variety of applications. Food contact grades available.
ColourNatural, Black, Blue & Various Colours
SpecsOKULEN 1000
LT Service Temp90ºC
HMWPE PE500
HMWPE PE500 is a general purpose polyethylene with excellent mechanical properties suitable for less demanding applications that would otherwise require UHMWPE. Widely used in the New Zealand food industry.
ColourNatural, Black & Colours
SpecsOKULEN 500
LT Service Temp90ºC
Polypropylene
Polypropylene offers a good balance of thermal, chemical and electrical properties with moderate strength. Available as either copolymer or homopolymer. A cost effective material suitable to a wide range of applications.
ColourNatural, Black, White, Beige
SpecsOKULEN PP
LT Service TempPP-C 80ºC/PP-H 100ºC
