PVDF Plastic
PVDF plastic (polyvinylidene fluoride) is a low density fluoropolymer generally used in applications requiring higher purity, higher mechanical strength, higher dimensional stability & resistance to solvents, acids & hydrocarbons when compared to standard fluropolymers. Continuous service temperature -30°C/+150°C, near zero moisture absorption & food grade compliance.
Excellent mechanical properties when compared to standard fluoropolymers
Outstanding resistance to minerals, acids, hydrocarbons, alcohols & solvents
High abrasion, UV resistance & flame retardant
Availability
Rod
4mm to 300mm OD
Tube
25mm ID to 90mm OD
Sheet
5mm to 100mm Thick
Colours
White, Black
Modified Grades
Yes
Cut To Size
No – minimum order quantities apply
Features
Food Grade
TECAFLON PVDF plastic is FDA compliant, non-toxic & can be used in repeated contact with food products. Food Certification documentation can be supplied at time of order to align with your production batch. (charges apply).
Additives & Modifiers
TECAFLON PVDF is available in the natural unfilled grade as well as TECAFLON PVDF ELS Black which is electrically conductive or TECAFLON PVDF CF8 which is carbon filled. Modified grades are imported on request & may be subject to minimum order quantities.
Applications
Often used as an insulation or protective barrier in the chemical industry. Chemical, food or pharmaceutical applications requiring higher mechanical strength & loading such as valves, fittings or pipelines. Commonly replaces PTFE where higher mechanical or abrasion resistance is required.
Long Term Service Temp
'-30ºC to +150ºC
Moisture Absorption
UV Stable
Compressive Strength
Impact Strength
Tensile Strength
Coefficient of Friction
Abrasion Resistance
Cost
TECAFLON PVDF Plastic Range
| Product Type | Product Code | Available Products & Notes |
|---|---|---|
| TECAFLON PVDF Natural | PVDF Natural | Rod, Tube, Sheet - White |
| TECAFLON PVDF ELS | PVDF ELS | Electrically Conductive. Black. Manufacture & import on request. |
| TECAFLON PVDF CF8 | PVDF CF8 | Carbon Fibre reinforced. Manufacture & import on request. |
